GBT AC EV Chargers can be classified based on output power. Low-power ones, around 3.6 kW to 7 kW, are suitable for home use, allowing overnight charging for daily commutes. Medium-power chargers, 11 kW – 22 kW, are applicable in both commercial and residential settings like office complexes and apartment buildings. High-power GBT chargers, above 22 kW, are mainly used commercially at public charging stations and high-traffic areas to provide rapid charging for EVs on the go, enhancing the convenience and usability of electric vehicles
Business Use 7KW 32A Wallbox GBT Plug AC Charging Pile
1. Charging Power: 7KW
2. Output Voltage: 220V, 1 phase
3. Output Current: 32A
4. Charging Interface Type: GB/T
5. Compatibility: Compatible with 99% of pure electric and hybrid electric vehicles on the market
6. Charging Efficiency: 90%
7. Protection Level: IP65
8. Operating Temperature Range: -30℃～+55℃
9. Device Size: W210mm*D94mm*H317mm
10. Net Weight: 5.3kg
11. Communication: 4G/Wifi/Ethernet/OCPP1.6J
Business Use Wall-mounted AC EV 14KW GBT Dual Port Charger
| Charging Power | 7KW*2 |
| Output Voltage | 220V, 1 phase |
| Output Current | 32A*2 |
| Charging Interface Type | GB/T |
| Compatibility | Compatible with 99% of pure electric and hybrid electric vehicles on the market |
| Charging Efficiency | 90% |
| Protection Level | IP54, IK10 |
| Operating Temperature Range | -30℃～+55℃ |
| Device Size | W275mmD125mmH385mm |
| Net Weight | 6.9kg |
| Display | Status light and 4.3-inch LCD screen |
| Communication | 4G/Wifi/Ethernet/OCPP1.6J |
Commercial Use 7KW GBT 32A Wallbox Charging Pile with 4.3 Inch LCD Display
1. Charging Power: 7KW
2. Output Voltage: 220V, 1 phase
3. Output Current: 32A
4. Charging Interface Type: GB/T
5. Compatibility: Compatible with 99% of pure electric and hybrid electric vehicles on the market
6. Charging Efficiency: 90%
7. Protection Level: IP65
8. Operating Temperature Range: -30℃～+55℃
9. Device Size: W210mm*D104mm*H317mm
10. Net Weight:5.4kg
11. Display: Status light and 4.3-inch LCD screen
12. Communication: Communication: 4G/Wifi/Ethernet/OCPP1.6J
GBT 7KW 32A Wallbox EV Charging Station for Home Use
1. Charging Power: 7KW
2. Output Voltage: 220V, 1 phase
3. Output Current: 32A
4. Charging Interface Type: GB/T
5. Compatibility: Compatible with 99% of pure electric and hybrid electric vehicles on the market
6. Charging Efficiency: 90%
7. Protection Level: IP65
8. Operating Temperature Range: -30℃～+55℃
9. Device Size: W210mm*D104mm*H317mm
10. Net Weight: 5.4kg
11. Display: Status light and 4.3-inch LCD screen
Home Use GBT 7KW 32A AC Electric Car Charging Station
1. Charging Power: 7KW
2. Output Voltage: 220V, 1 phase
3. Output Current: 32A
4. Charging Interface Type: GB/T
5. Compatibility: Compatible with 99% of pure electric and hybrid electric vehicles on the market
6. Charging Efficiency: 90%
7. Protection Level: IP65
8. Operating Temperature Range: -30℃～+55℃
9. Device Size: W210mm*D94mm*H317mm
10. Net Weight: 5.3kg
